CASE CL36EV
Big-machine ride. Electric torque. Zero emissions.
3.6-ton electric compact wheel loader with Z-bar linkage, 4,281 lb tipping load, 23 kWh battery, and diesel-comparable performance.
23 kWhBattery4,281 lbTipping Load8,911 lbWeight
23 kWh Battery
Instant electric torque
Quiet Operation
Indoor & noise-sensitive work
Zero Emissions
Enclosed space ready
Sonsray Service
30+ service locations
Overview
The Comfortable Way to Crush a Job — Quietly.
- Diesel-comparable digging, lifting, and breakout performance
- Instant electric torque from zero rpm
- 4,281 lb straight tipping load with Z-bar linkage
- 0.65 yd³ heaped bucket capacity
- Roomy cab with elevated point of view for full-site visibility
- Zero on-site emissions for indoor and restricted-site work
- Quiet operation for noise-sensitive contracts
- 12.4 mph travel speed for productive site-to-site moves
Features
Explore CASE CL36EV Features
Specifications
CASE CL36EV Specs
Specifications
General
Battery Capacity23 kWh
Operating Weight8,911 lb / 4,042 kg
Loader GeometryZ-Bar
Driveline
Max Forward Speed12.4 mph / 20 kph
Tire Size10.5-18
Dimensions
Length With Bucket On Ground17 ft 7 in / 5,369 mm
Height – Over Cab8 ft 1 in / 2,453 mm
Height – Pivot Pin10 ft 2 in / 3,088 mm
Full Lift Dump Height7 ft 7 in / 2,302 mm
Full Lift Reach3 ft 2 in / 957 mm
Bucket Width5 ft 5 in / 1,650 mm
Ground Clearance11 in / 279 mm
Capacities
Heaped Bucket Capacity0.65 yd³ / 0.5 m³
Performance
Straight Tipping Load4,281 lb / 1,942 kg
Full Turn Tipping Load3,728 lb / 1,691 kg
Loader ControlJoystick
